    During the session “RAG for Chatbots Using CrewAI”, held on 17 September, Jakub Kraśniewski, Senior AI Developer at TTMS, discussed improvements to a chatbot using a client’s documentation. He presented the challenges involved in preparing and retrieving information, the solution implemented and the approach to evaluating answer quality. The project involved a company in the education sector whose customers were preparing for a certification exam. The chatbot was intended to help them find information about registration, exam procedures, grading and appeals, thereby reducing the support team’s workload. It used several hundred pages of publicly available PDF documents, mainly in English. The team needed a way to retrieve relevant information from these materials while meeting a response time requirement of around 4 to 5 seconds.

    RAG AI

    1. How does RAG help a chatbot use company knowledge?

    Jakub began the presentation by explaining how RAG (Retrieval-Augmented Generation), a method of generating answers using retrieved source material, works. The system finds information relevant to the user’s question and passes it to a language model as context for the answer. In this project, the retrieved material consisted of passages from documentation describing exam rules and procedures.

    After extracting text from the documents, the system divides it into smaller chunks. An embedding model (an AI model that represents semantic features of text as numbers) converts these chunks into vectors stored in a database. The user’s question is processed in the same way. Comparing these representations allows the system to retrieve passages that are semantically related to the question. Jakub emphasised that the team is responsible for the quality of the material passed to the model. This involves checking whether the text was extracted correctly, whether the chunking preserved the necessary context and whether retrieval provides information useful for answering the question. The challenges the team encountered in the CrewAI-based solution demonstrated the importance of these steps.

    2. What made information retrieval difficult in the CrewAI project?

    After explaining the basics of RAG, Jakub shared his experience from a project using CrewAI, a framework for building AI agent-based systems. He discussed three problems encountered in the configuration used: overly large text chunks, the absence of an additional relevance assessment and errors in PDF text extraction.

    2.1 Overly large document chunks

    In the configuration Jakub described, text was split into chunks of 4,000 characters. The system retrieved five such chunks for each question, passing up to approximately 20,000 characters of source material to the model. A large chunk can contain information on several different topics, making it harder to match it to a specific question. The model generating the answer must then select the relevant information from the supplied content. In this project, the chunking approach therefore needed to be adapted to the structure of the documents and users’ questions.

    2.2 No additional assessment of search result relevance

    Jakub pointed out that the configuration lacked reranking, which involves reassessing and reordering search results according to their usefulness for answering the user’s question. The system can first retrieve a larger number of passages, then assess them further to select those most useful for preparing an answer. Jakub presented this method as a potential improvement whose value should be evaluated by checking both answer quality and response time.

    2.3 Incorrect text reading order in multi-column PDFs

    Another problem involved document text extraction. The tool read multi-column PDFs row by row, merging content from adjacent columns. This disrupted the order of sentences and made subsequent information retrieval more difficult. The resulting text was then split into chunks. The error therefore originated during data preparation and affected the subsequent stages of document processing. This example showed why evaluating RAG quality should begin with comparing the extracted text against the source document.

    RAG AI business

    3. How does response time affect the choice between Classic RAG, Agentic RAG and Graph RAG?

    A key project requirement was a response time of around 4 to 5 seconds. Jakub discussed three RAG approaches in terms of data preparation costs, the ability to evaluate their operation and the time needed to handle a question.

    Approach How it works, as discussed during the session What to consider when choosing
    Classic RAG Retrieves passages from a knowledge base, optionally reranks them and passes the context to the model. Document chunking quality, retrieval relevance and the amount of context provided.
    Agentic RAG An agent selects tools and a retrieval method, running additional queries as needed. The ability to adapt retrieval to the question, along with the time and cost of additional operations.
    Graph RAG Retrieval uses a knowledge graph describing entities found in the source material and the relationships between them. The effort required to build and maintain the graph, and how useful the relationships are for answering users’ questions.

    In an agentic approach, the model can use several tools, such as vector search, keyword search or filtering by metadata describing the document. Additional steps allow the system to expand its search for information, while their number and sequence affect response time. In the graph-based approach presented, some of the work takes place when building the knowledge base. Entities and the relationships between them are extracted from the text. This mechanism also underpins GraphRAG as described by Microsoft. Jakub highlighted the costs of this preparation and the difficulty of manually analysing a complex graph.

    In this project, the response time requirement favoured further development of classic RAG. The team focused on document chunking and context selection.

    4. How does hierarchical document chunking help preserve context?

    The solution organised the material into three connected levels: pages, paragraphs and sentences. The system retained information about which paragraph each sentence belonged to and which page contained that paragraph. Content was represented in the vector database at different levels of detail. This allowed retrieval to identify both individual sentences and larger passages containing the required information. According to Jakub, the additional cost of storing and processing these representations was acceptable given the volume of material in the project.

    Finding a relevant sentence made it possible to retrieve its entire paragraph and provide the model with broader context. The system could also retrieve the whole page when needed. Suppose a user asks about the deadline for appealing an exam result. The system finds a sentence specifying the deadline, then retrieves the entire paragraph explaining when the appeal period begins and how to submit an appeal. This allows the model to account for these conditions in its answer.

    5. How can you evaluate RAG quality using your own data?

    In the final part of the presentation, Jakub emphasised the importance of a benchmark, a set of tests used to compare different versions of a solution. He discussed checking retrieval results against information labelled by a human and using a language model to evaluate answers. In practice, it is useful to assess two stages separately. The first concerns retrieval: did the system return a passage containing the required information? The second concerns the answer: did the model use the supplied material correctly? This distinction helps identify which stage needs improvement.

    In additional information shared after the session, Jakub clarified the testing method and results. The test set included questions covering the full scope of the documentation, along with real user questions collected anonymously during a prototype launch at the beginning of the year. Answer accuracy increased from around 70% to around 98%, an improvement of approximately 28 percentage points. This result applies to the internal test conducted in this project. According to Jakub, the solution also maintained a fast response time. When he shared these details, the chatbot had completed internal testing, and the company planned to make it available to a subset of customers. Reducing the support team’s workload and making information easier to access remained deployment goals. Assessing whether those goals have been achieved requires data from actual use.

    The embedding model is another component to evaluate. Jakub noted that its selection should take into account the language of the source material and its performance on the team’s own dataset. The choice of this model affects which passages the system retrieves before it begins generating an answer.

    6. What can companies implementing a chatbot learn from this experience?

    The project shows how specific requirements guide RAG development. The expected response time helped narrow down the choice of solution, document analysis revealed problems with text extraction and chunking, and an internal test made it possible to assess the impact of the changes.

    When planning a similar implementation, it is worth addressing five areas:

    • Source material: check whether document text extraction preserves meaning and reading order.
    • Document chunking: adapt chunk size and the connections between chunks to the structure of the material.
    • User questions: prepare a test set that reflects the tasks the chatbot is intended to support.
    • Response time: establish expectations and account for them when comparing approaches.
    • Quality assessment: check both the relevance of the retrieved information and how it is used in the answer.

    Let’s talk about AI in your company

    TTMS is home to experts who, like Jakub, combine technical knowledge with experience from client projects. During Tech Talks, they share solutions tested in practice and apply what they have learned to subsequent implementations.

    What documents can a RAG chatbot use as a knowledge base?

    A RAG chatbot can use company policies, product manuals, procedures, FAQs and other materials containing information relevant to its users. Sources may include PDFs, Word documents, website content and knowledge base articles, depending on the integrations available. Scanned documents require optical character recognition (OCR) to turn images of text into searchable content. Tables, diagrams and complex layouts may need additional processing to preserve their meaning. Before adding documents, check that they are accurate, current and approved for the intended audience. Clearly structured materials help the system retrieve information and provide useful context for its answers.

    How do you keep a RAG chatbot’s knowledge base up to date?

    Keeping a RAG chatbot up to date requires a process for detecting and processing changes in its source materials. Depending on business needs, updates can run on a schedule or be triggered when a document is added, edited or removed. The system then updates the searchable content and its associated representations, such as embeddings. Version information and effective dates help distinguish current guidance from older material. Deleted or superseded documents should also be removed from active search results, and cached answers may need refreshing. Assigning an owner to each content area helps ensure that someone remains responsible for the information the chatbot uses.

    Can a RAG chatbot provide sources for its answers?

    Yes, a RAG chatbot can include links, document titles, page numbers or quoted passages alongside its answers. This requires the system to preserve source information when processing documents and connect retrieved passages to the response. Useful citations let users open the relevant material and check the context for themselves. The system should also verify that each citation supports the claim it accompanies. A source link alone provides no guarantee that an answer accurately reflects the document. During testing, teams should check both answer quality and citation accuracy, including whether users can access the referenced material.

    How can a RAG chatbot respect access permissions for company documents?

    A RAG chatbot can use the signed-in user’s identity and access rights to determine which documents it may retrieve. Permission checks should happen before restricted content reaches the language model. The same controls need to cover document previews, citations and any cached responses that contain protected information. When access rights change in a source system, those changes must also be reflected in the chatbot’s retrieval process. Teams should test the solution using accounts with different roles, including users with limited access. These checks help confirm that each person receives answers based on information they are authorised to view.

    What should a RAG chatbot do when it cannot find an answer?

    When the available documents provide insufficient information, a RAG chatbot should clearly explain that it cannot answer reliably from its sources. It can ask a clarifying question if the request is ambiguous or suggest a related document that may help. For questions requiring further assistance, it can direct the user to the appropriate team or support channel. The system needs explicit rules for handling incomplete, conflicting or missing information. Testing should include questions whose answers are absent from the knowledge base, so the team can assess this behaviour. Reviewing unanswered questions can also reveal gaps in company documentation and priorities for future updates.
